FITTINGS

PE 100 SDR 11 (ISO S5)10 bar Gas / 16 bar WaterWith integral pipe fixation4 mm pin connectorsLimited path fusion indicatorsSupplied as a k it - - - - - - - -

Suitable for all kinds of pipe material. For use on plastic pipes please consult Georg Fischer Waga N.V.Single band clamp with full circle gasketAll metal parts are stainless steel, quality AISI 304 (on request AISI 316)The rubber gasket is available in NBR (EPDM on request)Water and gas: NBR according to EN 682 (-10°C up to +70°C); potable water: EPDM according to EN 681-1 (-10°C up to +55°C)For working pressures in GAS please consult Georg Fischer Waga N.V.To choose the correct length of Multi/Clamp check our technical information - - - - - - -

10 bar Gas / 16 bar WaterOnly for ELGEF Plus Couplers and FittingsStainless steel V2A (1.4305) - - - - - - - - -

10 bar Gas / 16 bar WaterBranch Saddle installation only with installation set Topload TL225 (799.300.807)Angle adaptors (799.350.340) for fusion cable required 4 mm pin connectorsLimited path fusion indicatorsSpigot outlet for butt- and electrofusionFull pressure applicable - no derating factorWith integrated pressure test port for test c ap (799.199.287) - - - - - - -

"NBR = Nitrile rubber hardness approx. 80° ShoreFor all metric GF Flange AdaptorsRubber-steel body combined with rubber profile cord ring up to d630Rubber-steel body ideal for big " dimensions (d710 - d1000)Approved acc. to DVGW standard DIN EN 682 for gasD corresponds to the centring at the inner diameter of the screw crown

Conventional butt-welding according to DVS 2207IR = Infrared-(IR Plus) compatible. Choose fusion parameters: PE1005 bar Gas / 10 bar Water - - - - - - - - -

10 bar Gas / 16 bar Water 4 mm pin connectors Limited path fusion indicators Two separate fusion zones - - - - - - - - -

10 bar Gas / 16 bar Water4 mm pin connectorsLimited path fusion indicators - - - - - - - - -

Universal peeling for the preparation of all electrofusion joints For pipe ends and saddles Materials: PE 80, PE100, PE100-RC, PE-X, PP - - - - - - - - -

10 bar Gas / 16 bar Water4 mm pin connectorsLimited path fusion indicatorsWith integral pipe fixation - - - - - - - - -

For ELGEF Plus ball valve d20-d110mmExtension spindle acc. to DVGW GW336Steel square connection 20x20mm for d20-75Steel square connection 25x25mm for d90-d1 10Continuously adjustable and self-supportingPullout- and dirt-safeRod hot-dip galvanizedPE-casing and PE-centering cap with gasketInclusive clip-pin out of stainless stell - - - - - - -

With solvent cement spigot and socket metric - - - - - - - - -
